MH-V200 Step Pulley Milling Machine Head
Upgrade or replace your existing mill head with the MH-V200 Step Pulley Milling Machine Head. Designed as a complete replacement head for worn machine bodies, rebuilds, and custom machinery, this head delivers exceptional precision, durability, and an expanded speed range for demanding machining applications.
Featuring a chrome-plated quill, super precision pre-loaded spindle bearings, and an R8 spindle, the MH-V200 provides outstanding accuracy, rigidity, and long-lasting performance.
Specifications
- Model: MH-V200
- Type: Step Pulley Milling Machine Head
- Motor: 3 HP
- Voltage: 220V, 3-Phase
- Spindle: R8
- Speed Range: 80–5,600 RPM
- Drive System: 16-Speed Step Pulley
Precision Specifications
- Chrome-plated quill
- Super precision pre-loaded spindle bearings
- Spindle Nose Taper Runout: 0.0002″ (0.005 mm) TIR
- Quill Power Feed Rates:
- 0.0015″ per revolution
- 0.003″ per revolution
- 0.006″ per revolution
Features
- Complete replacement milling machine head
- Ideal for replacing worn Bridgeport-style heads or for custom machine applications
- 16-step pulley speed system with a wide operating range
- Precision R8 spindle compatible with standard R8 tooling
- Chrome-plated quill for improved wear resistance and smooth operation
- High-precision pre-loaded spindle bearings for maximum accuracy
- Industrial-grade construction for dependable, long-term performance
Important Note
Please verify your mounting dimensions, electrical requirements, and machine compatibility before ordering. This head is designed for 220V, 3-phase power and features a 16-step pulley drive system.
