MS942 / 3HP Step Pulley Vertical Turret Milling Machine
The MS942 3HP Step Pulley Vertical Turret Milling Machine is a heavy-duty, precision-built machine designed for reliable performance in machine shops, toolrooms, maintenance departments, and production environments. Featuring a 9″ × 42″ hardened and ground work table, powerful 3 HP spindle motor, and versatile R8 spindle taper, the MS942 is well suited for a wide range of milling, drilling, boring, and general machining applications.
With a 16-step spindle speed range of 80–5,440 RPM, generous table and knee travel, and precision hardened and ground ways, this vertical turret milling machine provides the versatility and accuracy needed for everyday machining operations. Durable Meehanite castings, precision bearings, Turcite-lined saddle ways, and an integrated lubrication system help provide smooth operation and long-term reliability.
Standard Features
- Heavy-duty Meehanite casting construction
- 9″ × 42″ hardened and ground work table
- Precision Grade Class 7 bearings
- Precision hardened and ground ways
- Turcite-lined saddle ways
- Double-lock nuts on both X and Y axes
- Chrome-plated quill and honed head
- Automatic quill feed
- Coolant system with nozzle and valve
- Integrated lubrication system
- ISO 9002 certified
Specifications
| Specification | Details |
|---|---|
| Work Table | 9″ × 42″ |
| Table Travel | 36″ × 12″ × 16″ |
| T-Slot Size | 5/8″ |
| Longitudinal Travel (X) | 30″ |
| Cross Travel (Y) | 12″ |
| Knee Travel (Z) | 16″ |
| Quill Travel | 5″ |
| Ram Travel | 12″ |
| Spindle to Column (Max./Min.) | 18-1/2″ / 6-3/4″ |
| Spindle to Table (Max./Min.) | 18″ / 2-1/8″ |
| Quill Diameter | 3-3/8″ |
| Spindle Taper | R8 |
| Spindle Speed Range | 80–5,440 RPM (16 steps) |
| Automatic Quill Feed | 0.0015″ / 0.003″ / 0.006″ per revolution |
| Spindle Motor | 3 HP |
| Electrical Supply | 220V, 3-phase, 60 Hz, prewired |
| Weight | 2,200 lbs. |
Parallelism
- X-Axis: 0.0008″ over 20″
- Y-Axis: 0.0008″ over 12″
- Knee Axis: 0.0008″ over 12″
- Ram: 0.0008″ over 12″
- Quill: 0.0005″ over 5″
The MS942 Vertical Turret Milling Machine combines traditional step pulley versatility with durable construction and precision components, making it an excellent choice for shops looking for a dependable, full-featured milling machine.
