MV1054-KV3 Vertical Turret Milling Machine
The MV1054-KV3 Vertical Turret Milling Machine is a heavy-duty, precision-built machine designed for demanding machining applications in machine shops, toolrooms, maintenance departments, and production environments. Featuring a large 10″ × 54″ work table, generous axis travel, and a powerful 3 HP variable-speed spindle, this versatile milling machine provides the capacity and flexibility needed for a wide range of milling, drilling, boring, and general machining operations.
Built with durable Meehanite castings, hardened and ground X, Y, and Z ways, and Turcite-B coated guideways, the MV1054-KV3 is designed for smooth operation, rigidity, and long-term accuracy. Precision Class 7 spindle bearings and C7 double-nut precision ACME lead screws further support dependable and accurate machining.
The variable-speed head features a spindle speed range of 70 to 4,200 RPM with Hi/Lo gears, allowing operators to select the appropriate speed for a variety of materials and applications. Standard features include one-shot lubrication, a built-in halogen work light, and a chip-rubber cover.
Standard Features
- Heavy-duty Meehanite casting construction
- 10″ × 54″ work table
- Hardened and ground X, Y, and Z ways
- Turcite-B coated guideways
- Variable-speed head with Hi/Lo gears
- Spindle speed range of 70–4,200 RPM
- Precision Class 7 spindle bearings
- C7 double-nut precision ACME lead screws
- One-shot lubrication system
- Built-in halogen work light
- Chip-rubber cover
- R8 spindle taper
Specifications
| Specification | Details |
|---|---|
| Model | MV1054-KV3 |
| Table Size | 10″ × 54″ |
| X-Axis Travel | 36″ |
| Y-Axis Travel | 15.75″ |
| Z-Axis Travel | 16″ |
| Quill Travel | 5″ |
| Quill Diameter | 3.38″ |
| Ram Travel | 24″ |
| Spindle Nose to Tabletop | 1.96″–18″ |
| Table Load Capacity | 770 lbs. |
| T-Slot Size | 0.62″ × 2.55″ |
| Spindle Taper | R8 |
| Spindle Speed | 70–4,200 RPM with Hi/Lo gears |
| Head Swivel | ±90° |
| Head Tilting Angle | ±45° |
| Spindle Power | 3 HP |
| Coolant Pump | Optional, 1/8 HP |
| Lubrication Pump | One-shot |
| Floor Plan | 110″ × 100″ × 89″ |
| Net Weight | 2,860 lbs. |
| Power Requirement | 4 KVA, 3-phase, 208–230V max |
| Air Requirement | Optional power drawbar, 90–100 PSI |
DRO and power feed are not included.
The MV1054-KV3 Vertical Turret Milling Machine combines a large-capacity work table, extended ram travel, generous Y-axis travel, and precision construction to deliver dependable performance for a wide variety of machining applications.
